ProSoft RLX2-IHNF-WC RadioLinx Weatherproof Fast Industrial Hotspot

Technical Specifications

Model:RLX2-IHNF-WC

Brand:ProSoft

Product type:RadioLinx IP66/IP67 Weatherproof 802.11abgn Industrial Wi-Fi Transceiver

Power supply:10~30VDC or 802.3af PoE

Radio frequency:2.4GHz & 5GHz dual band,support DFS radar detection channel

Wireless rate:max 300Mbps,MIMO 22

Communication interface:210/100Mbps Ethernet RJ45,1RS232 serial port,3N-type antenna ports

Roaming switchover:<10ms

Protection grade:IP66/IP67

Weight:2.7kg

Operating temperature:-40℃ ~ +70℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:5%~95%,non-condensing

Dimension:292mm178mm70mm

Certification:CE,UL,FCC,Class I Division2

System compatibility

RLX2-IHNF-WC belongs to ProSoft RadioLinx RLX2 series outdoor waterproof industrial Wi-Fi hotspot.

Supports Access Point,Client,Repeater three working modes.

Compatible with Rockwell,Schneider,Siemens PLC,support EtherNet/IP,Modbus TCP industrial Ethernet communication.

Suitable for offshore platform,mining site,outdoor pipeline,port crane,field SCADA wireless network renovation and spare replacement.

Function

Dual band 802.11abgn MIMO wireless technology,supports high-speed industrial control data transmission.

Ultra-fast roaming less than 10ms,realize seamless handover for moving automation equipment.

Built-in EtherNet/IP object and Modbus agent,radio diagnostic data can be directly read by PLC.

WPA2 AES encryption,MAC filtering,RADIUS authentication and VLAN for industrial network security isolation.

QoS and IGMP snooping function,optimize EtherNet/IP multicast I/O traffic.

IH Browser software for network topology view,IP allocation,online diagnosis and firmware upgrade.

Supports SNMP and optional OPC diagnostic server for centralized wireless network monitoring.

Transparent wireless bridge for industrial Ethernet and RS232 serial data transmission.

MicroSD card slot for configuration backup and quick device replacement.

Installation

Mount module on wall or pole bracket,power supply via DC terminal or 802.3af PoE.

Install matched outdoor antennas on N-type ports,add lightning protection for long cable runs.

Connect Ethernet cable to PLC or industrial switch,serial port for optional serial field equipment.

Set working mode,SSID and security parameters via IH Browser software.

Check wireless signal strength and LED indicators after power-on.

Interface

210/100Mbps Ethernet RJ45,1RS232 terminal port,3*N-type antenna connectors,power terminal,microSD card slot,LED indicators:PWR,WLAN,COM,NET.

Feature

IP66/IP67 cast aluminum waterproof enclosure,designed for outdoor severe weather,dust and moisture resistance.

10ms ultra-fast roaming,meets real-time control requirement of mobile automation equipment.

Dual band optional,reduce 2.4GHz frequency band electromagnetic interference.

Built-in web server for local configuration and equipment status monitoring.

Support configuration backup by microSD card,fast on-site replacement.

Shock and vibration resistant design,20G shock resistance,suitable for offshore and mining harsh environment.

Diagnostic

Check module power and WLAN LED;communication failure:check antenna,cable and channel interference;data abnormal:verify SSID,encryption setting and roaming parameter.

Product Brief

RLX2-IHNF-WC is ProSoft RadioLinx RLX2 series IP67 outdoor waterproof fast industrial Wi-Fi hotspot.

It provides low latency and high reliability outdoor wireless communication for offshore,mining and field SCADA system,widely applied in EtherNet/IP industrial wireless system maintenance and transformation.
