ProSoft RLXIB-IHA-A RadioLinx 802.11a Industrial Hotspot

Technical Specifications

Model:RLXIB-IHA-A

Brand:ProSoft

Product type:RadioLinx legacy 802.11a 5GHz Industrial Hotspot Wireless Transceiver

Power supply:10~30VDC

Radio frequency:5GHz 802.11a

Wireless rate:max 54Mbps

Transmit power:250mW

Communication interface:210/100Mbps Ethernet RJ45,1RS232 serial port,3RP-SMA antenna ports

Roaming switchover:<10ms

Weight:0.56kg

Operating temperature:-40℃ ~ +70℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:5%~95%,non-condensing

Dimension:125mm90mm*45mm

Certification:CE,UL,FCC,Class I Division2

System compatibility

RLXIB-IHA-A belongs to ProSoft legacy RadioLinx RLXIB series industrial Wi-Fi hotspot.

Supports Access Point,Client,Repeater three working modes.

Compatible with Rockwell,Schneider,Siemens PLC,support EtherNet/IP,Modbus TCP industrial Ethernet communication.

Can intercommunicate with RLX2 series radios.

Suitable for automotive production line,AGV trolley,warehouse mobile equipment,legacy factory wireless SCADA network renovation and spare replacement.

Function

5GHz 802.11a wireless technology,free from 2.4GHz frequency interference.

Ultra-fast roaming less than 10ms,realize seamless handover for moving automation equipment.

Built-in EtherNet/IP object and Modbus agent,radio diagnostic data can be directly read by PLC.

WPA2 AES encryption,MAC filtering,VLAN for industrial network security isolation.

QoS and IGMP snooping function,optimize EtherNet/IP multicast I/O traffic.

IH Browser software for network topology view,IP allocation,online diagnosis and firmware upgrade.

Supports SNMP for centralized wireless network monitoring.

Transparent wireless bridge for industrial Ethernet and RS232 serial data transmission.

Support RSTP rapid spanning tree protocol to prevent network loop.

Installation

Mount module on DIN rail,connect 10~30VDC power supply.

Install matched 5GHz antennas on RP-SMA ports.

Connect Ethernet cable to PLC or industrial switch,serial port for optional serial field equipment.

Set working mode,SSID and security parameters via IH Browser software.

Check wireless signal strength and LED indicators after power-on.

Interface

210/100Mbps Ethernet RJ45,1RS232 terminal port,3*RP-SMA antenna connectors,power terminal,LED indicators:PWR,WLAN,COM,NET.

Feature

DIN rail compact industrial legacy design,wide temperature range for harsh factory environment.

5GHz exclusive band,avoid heavy 2.4GHz interference in dense factory workshops.

10ms ultra-fast roaming,meets real-time control requirement of mobile automation equipment.

Built-in web server for local configuration and equipment status monitoring.

RSTP spanning tree support for redundant network architecture.

Shock and vibration resistant design,stable operation in industrial cabinet environment.

Diagnostic

Check module power and WLAN LED;communication failure:check antenna,cable and channel interference;data abnormal:verify SSID,encryption setting and roaming parameter.

Product Brief

RLXIB-IHA-A is ProSoft legacy RadioLinx RLXIB series 5GHz 802.11a industrial Wi-Fi hotspot.

It provides low latency and high reliability wireless communication for factory mobile automation equipment,widely applied in EtherNet/IP and SCADA legacy industrial wireless system maintenance and transformation.

Disclaimer

Product parameters are for reference only and shall not be used as pricing basis. Goods are in short supply and will be powered on for inspection before shipment. Overseas delivery lead time is 3-7 working days. The product is only used for equipment maintenance and transformation.
