QC323-AR9TTL-VED-IA Signal Converter Unit

Feature & Principle

This signal module adopts electrical isolation design, realizes mutual conversion between analog 4-20mA signal and TTL pulse signal. It suppresses ground loop interference, transmits standard signals to PLC, counter and display instrument for measurement and control.

Specifications

Model: QC323-AR9TTL-VED-IA Brand: Unknown Type: Isolated signal converter Input: Analog / TTL pulse Output: TTL / analog Power supply: 24VDC Isolation: Electrical isolation Mounting: DIN rail mounting Protection: IP20 Certification: CE

Components & Diagnostics

Isolation chip, signal processing circuit, terminal block, status indicator. Common faults: signal loss, conversion offset, power failure, interference abnormal.

Product Brief

QC323-AR9TTL-VED-IA signal converter, automation spare widely used for instrument signal matching and pulse acquisition.
