QPP-0002 Quad Processor Pack Unit

Feature & Principle

It adopts 1oo2D synchronous dual-processor redundant design. Two processors run safety logic synchronously, hardware comparator checks calculation consistency, high diagnostic coverage rate. It collects field safety I/O signals, executes ESD and safety interlock programs. Dual modules can be configured for redundancy through dedicated synchronous bus, to ensure safety system continuous operation when single module fails.

Specifications

Model: QPP-0002 Brand: Honeywell System: Safety Manager SIS Safety level: SIL3 Power supply: 24VDC Mounting: Rack plug-in Compatibility: Backward compatible with QPP-0001 (R121 firmware and above) Certification: TUV, FM, CE

Components & Diagnostics

Synchronous dual processor chip, flash memory, battery backup RAM, watchdog circuit, redundant communication transceiver, status LED, I/O bus driver. Common faults: backup battery exhausted, communication synchronization failure, module offline, watchdog alarm, boot failure.

Product Brief

QPP-0002 processor pack, Honeywell SIS safety spare widely used for petrochemical, refinery and natural gas plant emergency shutdown safety cabinet maintenance.
