Rexroth 0608820-115 Spare Part

Technical Specifications

Model:0608820-115

Brand:Rexroth

Product type:Torque and angle measurement transducer

Power supply:±15 Vdc

Control function:Real-time torque-angle acquisition,strain signal conversion,hardware self-diagnosis,fault indication

Communication:Analog signal / internal system bus

Mounting:Flange mounted on tightening spindle

Operating temperature:0~55℃

Storage temperature:-40~70℃

Relative humidity:5~95% non-condensing

Max working altitude:2000m

Weight:0.55kg

Dimension:114mm76mm38mm

Certification:CE,UL

Protection class:IP67

System compatibility

0608820-115 belongs to Rexroth servo nutrunner tightening system shturl.cc matches with tightening spindle,drive unit and tightening controller.Widely used in automobile assembly bolt tightening stations.This is a discontinued legacy spare part for equipment maintenance replacement.

Function

0608820-115 is Rexroth high precision measuring transducer for electric nutrunner.It detects torque and rotation angle values during bolt fastening.It converts mechanical strain signal into standard electrical signal and transmits measurement data to tightening controller.It ensures high precision closed-loop torque control and stores assembly data for quality traceability.It continuously monitors sensor working state and sends fault alarm messages to upper control unit.It acts as core measuring component of Rexroth nutrunner workstation.

Installation

Mount 0608820-115 on spindle flange and tighten fixing bolts.Complete power and signal wiring following wiring diagram.Check ±15V power polarity and shield grounding before power-on.

Interface

‑±15Vdc power input terminal

‑Torque & angle signal output connector

‑Internal bus terminal block

‑Status and fault LED indicator

Circuit feature

Built-in ESD and surge suppression circuit,sensor signal galvanic isolation design,strong anti-interference performance for industrial workshop environment.

Feature

0608820-115 is obsolete Rexroth spare part.Typical failures:torque reading drift,intermittent signal loss,measurement deviation,connector pin corrosion.Inspect sensing element and connector pins before replacement.This transducer must match corresponding Rexroth tightening spindle and controller,direct substitution without inspection is not recommended.

Diagnostic

When signal attenuation,overload or internal hardware fault occurs,the module triggers protection and lights up fault LED.

Built‑in function:High precision torque-angle measurement,mechanical-electrical signal conversion,status monitoring,self-diagnosis and fault alarm,used as Rexroth servo tightening system spare replacement.

Product Brief

0608820-115 is Rexroth torque angle transducer for nutrunner assembly workstation.Confirm compatibility with matched spindle and tightening controller before ordering.ESD protection required during handling and installation.
