Rexroth 608800048 Spare Part

Technical Specifications

Model:608800048

Brand:Rexroth

Product type:Servo tightening system control board

Power supply:24 Vdc,19.2~28.8V tolerance

Control function:Torque angle closed-loop calculation,signal processing,parameter storage,hardware self-diagnosis,fault indication

Communication:System internal bus

Mounting:Plug-in installation

Operating temperature:-10~55℃

Storage temperature:-20~70℃

Relative humidity:5~95% non-condensing

Max working altitude:2000m

Weight:0.28kg

Dimension:185mm76mm33mm

Certification:CE

Protection class:IP20

System compatibility

608800048 belongs to Rexroth servo tightening system family,matched with tightening spindle and related drive units.Widely applied in automobile assembly tightening workstations.This is a discontinued legacy spare part for equipment maintenance replacement.

Function

608800048 serves as Rexroth servo tightening system control board.It receives torque and angle feedback signals from the spindle,executes closed-loop tightening algorithm and outputs control instructions to servo drive.It stores tightening program parameters and records assembly process data.It monitors real-time running status and uploads fault alarm information to upper host.It acts as core signal processing and control component for Rexroth tightening workstation.

Installation

Install 608800048 to designated slot and lock fasteners.Complete power and signal wiring according to wiring drawing.Check 24V power polarity and equipment grounding before power-on.

Interface

‑24Vdc power input terminal

‑Torque & angle signal terminal block

‑Internal bus connector

‑Status and fault LED indicator

Circuit feature

Built-in ESD and surge suppression circuit,signal galvanic isolation design,strong anti-interference performance for workshop industrial environment.

Feature

608800048 is obsolete Rexroth series spare part.Typical failures include program loss,abnormal torque control,communication interruption,connector pin oxidation.Check circuit board and connector pins before replacement.This board must match corresponding Rexroth tightening servo system,direct substitution without inspection is not recommended.

Diagnostic

When signal distortion,parameter error or internal hardware fault occurs,the module triggers protection and lights up fault LED.

Built‑in function:Torque-angle closed-loop control,signal processing,parameter storage,status monitoring,self-diagnosis and fault alarm,used as Rexroth servo tightening system spare replacement.

Product Brief

608800048 is Rexroth old control board for servo tightening assembly workstation.Confirm compatibility with corresponding tightening spindle and drive before ordering.ESD protection required during handling and installation.
