Rexroth APS-000-086-6 Power Supply Module Spare Part

Technical Specifications

Model:APS-000-086-6

Brand:Rexroth

Product type:Subrack plug-in power supply module

Input:3-phase AC

Output:DC bus voltage for servo rack

Mounting:Subrack plug-in installation

Weight:1.3kg

Operating temperature:0~45℃

Storage temperature:-20~70℃

Relative humidity:5~95% non-condensing

Protection class:IP20

Certification:CE

System compatibility

APS-000-086-6 belongs to Rexroth Indramat control rack series,supplies power for Indramat servo amplifier and control boards,widely used in CNC machine tools,press machines and automated production lines.This is a legacy spare part for industrial equipment maintenance replacement.

Function

APS-000-086-6 is a plug-in rack power supply module.It converts three-phase AC input into stable DC bus voltage for all modules in the control subrack.It supplies working power to servo amplifiers,interface boards and I/O modules,with built-in overvoltage,undervoltage and overcurrent protection.

Installation

Insert APS-000-086-6 into standard control subrack,tighten front panel fixing screws.Connect 3-phase AC power cable according to wiring diagram.Check terminal tightness and shield grounding before power-on commissioning.

Interface

‑3-phase AC input terminal

‑DC bus output terminal

‑Backplane bus connector

‑Status indicator terminal

Circuit feature

Switching power circuit design,fast fault detection,strong overload protection,stable voltage output,strong anti-interference,suitable for harsh workshop industrial environment.

Feature

APS-000-086-6 is obsolete Rexroth spare part.Typical faults:power rectifier damage,capacitor aging,overvoltage protection trigger,no DC output.Inspect AC input and DC bus output before replacement.This power supply must match original subrack and total load power,direct substitution without inspection is not recommended.

Diagnostic

When module fails,the whole rack will lose DC power,all servo axes stop and system trigger power failure alarm.

Built‑in function:Three-phase AC to DC conversion,DC bus power supply for rack modules,overload & overvoltage protection,used as Rexroth Indramat motion control system spare replacement.

Product Brief

APS-000-086-6 is Rexroth Indramat plug-in rack power supply for servo control cabinet.Verify input power and total load requirement before ordering.ESD protection required during handling and installation.
