Rosemount 8800DR060SA1N1D1E2M5R10Q4Q8YP Vortex Flowmeter

Feature & Principle

It is a wafer-type vortex flowmeter of Rosemount 8800D series. Based on Karman vortex street principle, it detects vortex frequency generated by fluid passing the bluff body and converts frequency signal into flow value. Without impulse piping and gaskets, it reduces leakage risk. Integrated temperature detection option realizes mass flow compensation. It supports HART digital communication, built-in advanced diagnostic functions, and meets SIL2 safety requirement. Widely used for gas, steam and liquid flow measurement in process industries.

Specifications

Model: 8800DR060SA1N1D1E2M5R10Q4Q8YP Brand: Rosemount (Emerson) Series: 8800D Size: 6 inch Output: 4-20mA, HART Design: Wafer installation SIL rating: SIL2 Wetted material: Stainless steel Protection: IP66 Certification: ATEX, IECEx, FM Application: Petrochemical, power plant, oil & gas, steam and compressed air metering

Components & Diagnostics

Shedder bar, piezoelectric sensor, transmitter electronic board, LCD display, process wafer body, terminal block. Common faults: sensor contamination, signal loss, display failure, output drift, overpressure damage.

Product Brief

8800DR060SA1N1D1E2M5R10Q4Q8YP vortex flowmeter, Rosemount no-impulse-piping flow measurement spare widely used for process pipeline overhaul and replacement.
