Rosemount 8800DR080SA3N1D1E2M5R10P2Q4Q8YP Vortex Flow Meter

Feature & Principle

It is Rosemount 8800D reducer vortex flow meter. It works on vortex shedding principle. Fluid passes the bluff body to generate regular vortices, the sensor detects vortex frequency and converts it into flow value. Gasket-free body removes leakage points and anti-clogging structure reduces blockage risk. It supports HART communication for remote configuration, calibration and diagnostic. Isolated sensor can be replaced without process shutdown. This reducer version is used to match smaller measuring range on larger pipeline.

Specifications

Model: 8800DR080SA3N1D1E2M5R10P2Q4Q8YP Brand: Rosemount (Emerson) Series: 8800D Type: Reducer vortex flowmeter Output: 4-20mA, HART 7 Wetted material: 316L stainless steel Accuracy: ±0.65% (liquid), ±1.0% (gas/steam) Turndown ratio: up to 38:1 Ingress protection: IP66 Certification: ATEX, IECEx, SIL optional Application: Petrochemical, power plant, steam, compressed air and process fluid measurement

Components & Diagnostics

Meter body, bluff body, vortex sensor, transmitter electronic head, local LCD display, process flange. Common faults: signal loss, unstable reading, sensor contamination, wiring failure, communication offline.

Product Brief

8800DR080SA3N1D1E2M5R10P2Q4Q8YP vortex flow meter, Rosemount 8800D reducer type flow measuring spare widely used for steam and process pipeline overhaul and replacement.
