Schneider NW3125T32V3WM02P09Z13 Masterpact NW ACB Unit

Feature & Principle

This intelligent air circuit breaker adopts Micrologic electronic trip unit. It provides overload, short circuit, earth fault and phase unbalance protection, supports power parameter measurement and fault recording. The withdrawable drawer structure allows isolated maintenance without full cabinet power cut, and supports Modbus communication to upload running data to upper monitoring system.

Specifications

Model: NW3125T32V3WM02P09Z13 Brand: Schneider Series: Masterpact NW Pole: 3P Frame current: 3200A Rated current: 1250A Mounting: Withdrawable drawer type Trip unit: Micrologic electronic protection Rated voltage: 400/415V AC Communication: Modbus Protection: IP30 (cabinet installation) Certification: IEC, CE

Components & Diagnostics

Electronic protection trip unit, main contact assembly, spring energy storage mechanism, drawer base, current transformer, communication module. Common faults: false tripping, contact overheating, energy storage failure, communication offline.

Product Brief

NW3125T32V3WM02P09Z13 air circuit breaker, Schneider low voltage main distribution spare widely used for factory power center, building power supply and auxiliary power system of power plant.
