SEW NBR 17049 Brazilian National Standard Compliance

Standard SpecificationsStandard No:ABNT NBR 17049 Brand:SEW Issuing Body:ABNT (Associação Brasileira de Normas Técnicas) Adopted from:ISO 17049 Document Type:Brazilian accessibility standard for tactile braille marking Applicable Product:SEW MOVIDRIVE MD60A, MDX61B, MOVITRAC series operating panels

ScopeThis standard defines braille dot geometry, dimension tolerance, material, surface finish and installation rules for SEW operator panels, control nameplates and warning labels when exporting SEW drives to Brazil. It ensures tactile braille marks can be reliably identified by visually impaired users.

Main Contents

1. Braille dot height, diameter and spacing tolerance requirements for SEW operation panel labels

2. Wear resistant material specification for braille tactile marks on SEW drive accessories

3. Braille character and line layout rules on SEW cabinet control plates

4. Mounting position and height requirements for SEW panel braille signage

5. Inspection and acceptance criteria for SEW braille marking

System compatibilityCompatible with SEW MOVIDRIVE MD60A, MDX61B, MOVITRAC series inverters and servo drives, DBG11A-01 / ABG11A-01 operator keypads. Required for Brazilian local machinery tender and INMETRO accessibility assessment.

Application FunctionSEW control panels can be customized with braille marking to meet ABNT NBR17049. Satisfy Brazilian accessibility regulation for industrial automation equipment exported to Brazil, ensure tactile identification on SEW drive operation interface.

Installation & Marking RequirementBraille marking fitted on SEW operator panel surface. Braille dimension, material and edge treatment must comply with ABNT NBR17049. No coating or paint covering braille dots after installation. Burr and sharp edges are forbidden.

InterfaceTactile braille dots on SEW drive operator panel, paired with standard text warning labels.

FeatureSEW drive optional customization solution complying with Brazilian ABNT NBR17049 accessibility standard. Applied on SEW servo & inverter operation panels for Brazil market export projects. Mainly used for packaging, logistics conveyor and material handling machine with accessibility requirements.

Diagnostic / Inspection ItemBraille dot dimension out of tolerance: non-compliant; Braille surface easy to wear: long term usability failure; Sharp burr on braille: safety non-compliance; Improper character spacing: cannot be read normally.

Product BriefSEW ABNT NBR17049 is the Brazilian accessibility standard compliance option for SEW MOVIDRIVE and MOVITRAC drive operator panels, specifying braille tactile marking requirements for equipment exported to Brazil.

DisclaimerAll parameters are for reference only and not the basis of quotation. Goods are scarce,overseas delivery lead time 3-7 working days. It is only used for equipment maintenance and retrofit.
