SEW BTS20-300-40-IGBT MOVIDRIVE External Brake Chopper IGBT Module

Technical SpecificationsModel:BTS20-300-40-IGBT Brand:SEW Product type:External Dynamic Brake Chopper IGBT Module Weight:4.2kg Dimension:240mm130mm340mm DC bus voltage:540~810VDC Rated braking power:40kW Max braking current:300A Protection class:IP20 Operating temperature:0℃ ~ 60℃ Storage temperature:-40℃ ~ +85℃ Relative humidity:5%~85%,non-condensing Certification:CE

System compatibilityBTS20-300-40-IGBT is SEW BTS20 series external brake chopper module. It matches MOVIDRIVE MD60A, MDX61B servo inverters and BPS10 shared power supply units. Used in multi-axis servo systems, packaging machinery, lifting and conveyor equipment for legacy drive system maintenance and spare replacement.

FunctionThis IGBT brake chopper module consumes regenerative energy generated by motor deceleration. When DC bus voltage exceeds threshold, IGBT turns on to connect braking resistor and release excess energy. It monitors DC bus voltage, IGBT temperature and braking current. Equipped with overvoltage, overcurrent and overtemperature protection, and fault signal output. Terminal block for DC bus and braking resistor wiring, LED status indicators on front panel.

InstallationPower off the whole DC bus system before installation. Mount BTS20-300-40-IGBT vertically inside control cabinet on metal backplate with fixing screws. Reserve sufficient ventilation space for heat dissipation. Separate high-voltage DC wiring and low-voltage control signal cables. Connect DC bus terminals and braking resistor terminals strictly following wiring diagram. After wiring, test voltage threshold and braking response before system operation.

InterfaceDC bus positive / negative terminal, braking resistor connection terminal, fault relay output terminal, shield grounding terminal, LED status indicators.

FeatureSEW BTS20-300-40-IGBT IP20 high-power external brake chopper. High current IGBT power core. Fast response for dynamic braking. Suitable for frequent start-stop and lifting load. Integrated temperature and current monitoring. Discontinued legacy spare part, only for MOVIDRIVE servo system maintenance replacement. Widely used for logistics conveyor, packaging automation and lifting machinery.

DiagnosticDC bus overvoltage alarm during deceleration: chopper failure or braking resistor open circuit; Overtemperature fault: insufficient cooling or dust accumulation; No braking action: wiring error or damaged IGBT chip; Continuous fault output: internal circuit damage.

Product BriefSEW BTS20-300-40-IGBT is BTS20 series 40kW external brake chopper IGBT module, used to absorb regenerative energy on DC bus for SEW MOVIDRIVE servo drive systems.

DisclaimerAll parameters are for reference only and not the basis of quotation. Goods are scarce,overseas delivery lead time 3-7 working days. It is only used for equipment maintenance and retrofit.
