SICK S30A-4011DA S3000 Professional Safety Laser Scanner

Feature & Principle

It is SICK S3000 Professional series safety laser scanner. It adopts 905nm infrared laser time-of-flight ranging principle, 190° scanning angle. It supports multi configurable protective and warning fields, 24 groups of field sets. When personnel or objects enter the protective zone, it triggers safe PNP shutdown output. It meets Type3 / SIL2 / PL d safety level, widely used for AGV collision avoidance and machinery area protection. This model is discontinued.

Specifications

Model: S30A-4011DA Brand: SICK Series: S3000 Professional Order code: 1028936 Protective field: 4 m, warning field up to 49 m Scanning angle: 190° Safety level: Type3, SIL2, PL d Power supply: 24VDC (16.8~28.8V) Output: 2 PNP safe outputs Protection class: IP65 Application: AGV, robot cell, machinery safety guarding, indoor only Certification: CE

Components & Diagnostics

Laser transmitting & receiving module, main control board, status indicator, M12 connector, polycarbonate protective window. Common faults: window contamination, laser signal weak, field configuration loss, safety output failure.

Product Brief

S30A-4011DA safety laser scanner, SICK S3000 series safety spare widely used for AGV and automation safety overhaul and replacement.
