SIEB & MEYER 0610520KF124243B Servo Power Cable

Module Feature

SIEB & MEYER 0610520KF124243B is pre-assembled shielded high-flex servo power cable. It is used to connect SIEB & MEYER servo power module and servo motor. Adopts multi-strand twisted conductors with overall copper braid shielding, provides excellent EMC performance to suppress switching noise. The outer jacket is oil-resistant, wear-resistant and suitable for continuous reciprocating bending inside cable drag chains. Both ends are fitted with molded metal connectors for fast and reliable assembly. Widely used in CNC machine tools, semiconductor processing equipment and precision automation production lines.

Working principle

Transmits three-phase AC power from servo power module to servo motor. The copper braided shield layer restrains electromagnetic interference generated by high-speed switching of IGBT power stage, protecting nearby encoder and low-level signal cables from noise distortion. Flexible multi-strand copper conductors maintain stable current transmission under repeated bending motion.

Onboard components

Multi-strand twisted power conductors, copper braided shielding layer, oil-resistant outer jacket, molded metal connector assembly, strain relief structure.

LED indicators

No LED indicators.

Hardware self-diagnosis

Visual inspection of cable jacket for cracks, abrasion and connector damage; continuity test of each power core; insulation resistance test between conductors and shield; check shield grounding integrity.

Programming software

No dedicated configuration software.

Electrical & Process Parameters

Model: 0610520KF124243B Rated voltage: 600V Conductor: Multi-strand flexible copper Shield: Copper braid shield Bending characteristic: High flex continuous bending Cooling: Natural ambient Protection: Oil resistant, abrasion resistant Mounting: Cable tray / drag chain routing

Mechanical & Structure

Mounting: Cable tray / drag chain routing Protection class: IP67 at connector mated state

Environmental

Operating temperature: -20℃ ~ +80℃ Ambient humidity: 5~95% non-condensing Certification: CE compliant Status: SIEB & MEYER high flex servo power cable assembly

System compatibility

Compatible with SIEB & MEYER series servo power modules and matched servo motors for CNC and semiconductor motion drive systems.

Function

0610520KF124243B servo power cable manufactured by SIEB & MEYER. It transfers three-phase power from power module to servo motor. The shielding reduces electromagnetic noise to protect nearby weak signal circuits. Cable insulation damage, poor connector contact or shield disconnection will cause drive alarm or unstable motor operation. It is essential wiring component for high precision servo motion system.

Installation

Follow lockout/tagout safety procedure before installation. Cut off all system power completely. Route cable inside drag chain or cable tray, reserve minimum bending radius, avoid friction with sharp edges. Connect both end connectors to power module and motor securely, ensure shield grounding. Power on and verify motor operation before formal operation.

Interface

Servo drive power connector, servo motor power connector, shield grounding terminal of 0610520KF124243B.

Diagnostic

Motor no rotation: Broken core wire, loose connector or no power output from drive. Drive overcurrent alarm: Cable insulation breakdown or short circuit between phases. Electromagnetic interference: Poor shield grounding or damaged shielding layer. Intermittent fault: Connector loose, cable fatigue fracture from repeated bending. Jacket damage: Abrasion by sharp mechanical parts.

Product Brief

0610520KF124243B SIEB & MEYER high flex shielded servo power cable,600V rated voltage,pre-terminated metal connectors,suitable for drag chain installation,used for connecting SIEB & MEYER servo drive and motor in CNC and semiconductor equipment.
