SIEMENS MOORE 15763-201 CR7 Controller Board with Power Supply

Technical SpecificationsModel:15763-201 CR7 Brand:SIEMENS MOORE Product Type:Mycro 352 Controller Board with Power Supply Power Supply:120V AC Mounting:Install inside Mycro 352 controller housing Operating temperature:-20℃ ~ +60℃ Storage temperature:-40℃ ~ +85℃ Relative humidity:5%~95%, non-condensing Weight:0.85kg Dimension:70mm145mm310mm

System compatibility15763-201 CR7 belongs to SIEMENS MOORE Mycro 352 single-loop controller series. It is the core main control board for Mycro352 panel mounted PID controller, matches controller housing, display panel and option expansion cards.

FunctionThis integrated controller & power board executes single-loop PID calculation, receives analog input signals from field transmitters and outputs control signals to regulating devices. It handles temperature, pressure, flow and liquid level closed-loop regulation. The on-board power circuit converts AC input to internal working power for the whole controller hardware, supports local setpoint adjustment, alarm logic and status indication.

InstallationCut off AC power before installation. Insert the board into Mycro352 controller enclosure, lock the board fixing bracket. Connect internal ribbon cable to display front panel. Wire AC power, analog I/O and alarm terminals according to wiring diagram. Complete PID parameter configuration and calibration after power on.

InterfaceInternal edge connector to front panel, analog signal terminals, alarm relay terminals, AC power input terminals, status LED indicators.

FeatureMycro352 dedicated main controller board with integrated power supply, single loop PID control, supports auto-tuning, alarm function, through-hole PCB design for stable operation in industrial environment. Obsolete legacy spare part, used for Mycro 352 loop controller maintenance and board replacement.

DiagnosticNo display: check AC power input, fuse and on-board power circuit. Control deviation: verify sensor input signal, recalibrate PID parameters. Alarm abnormal: inspect alarm relay circuit and process variable threshold setting.

Product BriefSIEMENS MOORE 15763-201 CR7 is Mycro352 series main controller board integrated power supply, widely used in petrochemical, boiler and water treatment industries for single loop PID process control.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
