SIEMENS MOORE 16066-1-0J Backplane Module

Technical SpecificationsModel:16066-1-0J Brand:SIEMENS MOORE Product Type:Rack Backplane Module System:APACS+ DCS System Power Supply:24V DC Mounting:Installed inside APACS rack chassis Operating temperature:-20℃ ~ +70℃ Storage temperature:-40℃ ~ +85℃ Relative humidity:5%~95%, non-condensing Weight:0.9kg Dimension:51mm152mm559mm

System compatibility16066-1-0J is compatible with SIEMENS MOORE APACS+ distributed control system. It is the core backplane board installed inside APACS rack, providing bus and power interface for ACM controller, analog I/O, discrete I/O and communication modules.

FunctionThis rack backplane module delivers DC power and high-speed system bus signal to all modules inserted in the rack. It interconnects each card slot to realize data exchange between controller and I/O modules. It serves as the central signal and power backbone of the whole DCS rack, supporting synchronous operation of all rack-mounted hardware.

InstallationCut off all rack power before installation. Secure backplane board to the inner frame of APACS rack. Confirm all backplane connectors are intact. Install power supply, controller and I/O modules into slots, ensure each module fully engages with backplane connector. Apply power and verify bus communication status.

InterfaceMulti-slot module connectors, power distribution terminals, system bus traces on PCB.

FeatureAPACS+ dedicated rack backplane, integrated power and signal bus, multi-slot connection, PCB with gold-plated connectors, robust structure. Obsolete legacy spare part, used for APACS+ DCS rack backplane replacement and system overhaul.

DiagnosticAll modules offline: inspect backplane power input and main connector damage. Individual module communication failure: check corresponding slot backplane contact and pin condition. Intermittent faults: check for oxidation, bent pins or mechanical loose contact.

Product BriefSIEMENS MOORE 16066-1-0J is APACS+ rack backplane module, widely used in petrochemical, power and pulp & paper industries as the internal bus and power backbone of APACS DCS control rack.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
