SLD04S5S Magnetostrictive Position Transducer

Feature & Principle

It adopts magnetostrictive measuring principle. The internal waveguide wire generates torsional wave under the excitation pulse, and the magnetic ring on the piston intercepts the signal. The controller calculates the absolute position by time difference. Non-contact structure, no mechanical wear, long service life. It has built-in signal conditioning circuit, strong anti-vibration and anti-interference capability, suitable for harsh hydraulic workshop environment.

Specifications

Model: SLD04S5S Type: Magnetostrictive linear sensor Output signal: 4-20mA / 0-10V optional Protection class: IP67 Measuring medium: Hydraulic oil Installation: Built-in cylinder installation Power supply: 24VDC Application: Injection machine, hydraulic press, metallurgical hydraulic cylinder Certification: CE

Components & Diagnostics

Waveguide wire, signal processing PCB, magnetic ring, stainless steel outer tube, aviation connector. Common faults: signal loss, position drift, connector water ingress, cable damage.

Product Brief

SLD04S5S magnetostrictive displacement sensor, industrial hydraulic sensor spare widely used for injection molding machine and hydraulic equipment maintenance and replacement.
