SWING2C0B0 Tuning Fork Level Switch Unit

Feature & Principle

It works on piezoelectric vibration principle. The fork vibrates at fixed frequency. When material covers the fork, vibration frequency changes, the internal circuit judges material arrival and outputs switch signal for high/low level alarm and feeding interlock control.

Specifications

Model: SWING2C0B0 Type: Tuning fork level switch Output: Relay / PNP switch output Power supply: 24VDC Process connection: Thread Protection: IP66 Certification: CE

Components & Diagnostics

Tuning fork probe, piezoelectric excitation element, main circuit board, terminal compartment, status indicator. Common faults: probe sticking, vibration stop, false alarm, signal no output, wiring corrosion.

Product Brief

SWING2C0B0 tuning fork level switch, material level spare widely used for cement, grain, plastic powder and chemical powder silo high and low level monitoring.
