SYSW80KHQ Static Switch Module Unit

Feature & Principle

It adopts thyristor static switching principle. It monitors inverter and bypass power voltage and phase condition in real time. When inverter is abnormal, it completes fast non-interruptive switching to bypass power supply, prevents load power failure, supports hot-swap replacement and UPS system status monitoring.

Specifications

Model: SYSW80KHQ Brand: Schneider APC Series: Symmetra PX Rated power: 80kW Rated voltage: 400V three-phase Mounting: Rack plug-in Status: Legacy UPS component Certification: CE, UL

Components & Diagnostics

Thyristor power unit, trigger control board, voltage detection circuit, cooling fan, bus terminal, status LED. Common faults: fan failure, SCR breakdown, switching failure, communication alarm, over-temperature protection.

Product Brief

SYSW80KHQ static switch module, APC UPS spare widely used for data center, industrial control room and precision equipment uninterruptible power supply cabinet maintenance.
