WAGO 750-613 System Power Supply Module

Feature & Principle

It adopts CAGE CLAMP spring terminal connection technology. It converts external 24VDC input into stable internal system power, expands the power capacity of the bus node. It provides power for the communication chip and logic circuit of I/O modules, supports hot swap, and can be cascaded with multiple power modules for large I/O stations.

Specifications

Model: 750-613 Brand: WAGO Series: 750 I/O system Output: 24VDC, 2A system power Field side pass through: 10A Mounting: DIN rail 35mm Width: 12mm Protection: IP20 Working temperature: 0~+55℃ Certification: CE, UL

Components & Diagnostics

Power conversion circuit, spring clamp terminal block, status LED indicator, overcurrent protection circuit. Common faults: no power output, LED not lit, output overload alarm, terminal poor contact.

Product Brief

750-613 power module, WAGO fieldbus I/O spare widely used for packaging, textile and general automation control cabinet I/O station power expansion.
