Woodward 8406-003 Operator Interface Panel

Feature & Principle

It communicates with the main controller through internal bus. Dual-screen LCD displays voltage, current, frequency, speed, temperature and alarm information. The membrane keypad is used for local operation, parameter modification and fault reset, supports redundant controller switching, suitable for diesel generator set and prime mover control.

Specifications

Model: 8406-003 Brand: Woodward Series: GENPART 6000 Display: Dual LCD screen Power supply: 18~36VDC Mounting: Panel cutout mounting Front protection: IP65 Application: Generator control, engine prime mover Certification: CE, marine approval

Components & Diagnostics

Dual LCD module, membrane keypad, main communication board, status indicator, bus interface terminal. Common faults: screen no display, keypad no response, communication interruption, data no refresh, backlight failure.

Product Brief

8406-003 operator panel, Woodward genset control spare widely used for standby diesel generator, marine power unit and engine control cabinet overhaul.
