XYCOM 301993 Operator Panel

Technical Specifications

Model:301993，P/N:89086-501

Brand:XYCOM

Product type:Panel Mount Operator HMI Panel

Power supply:115/230VAC auto-switching,50/60Hz

Display:Built-in industrial monochrome display

Input:Integrated sealed membrane function keypad

Communication:Serial RS232 interface

Mounting:Panel cutout installation

Weight:6.5kg

Operating temperature:0℃ ~ +55℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:5%~95%,non-condensing

Front panel:NEMA4/4X/12

Certification:CE,UL

System compatibility

301993 belongs to XYCOM legacy operator panel series.

It can communicate with XYCOM VME bus SBC such as XYCOM 1840 and XVME series I/O modules.

Compatible with turbine,compressor and legacy DCS control systems via serial port.

Commonly used for power plant,oil & gas,petrochemical old equipment monitoring,maintenance and spare replacement.

Function

Real-time display of process parameters,trend data and system alarm information.

Membrane keypad for setpoint adjustment,mode switching,alarm acknowledge and system operation.

Serial RS232 communication to exchange data with VME host controller.

Local alarm indication via front panel LED status lamps.

On-board self-diagnosis to detect communication failure and hardware fault.

Installation

Embed the panel into cabinet cutout and fasten mounting clips.

Connect 115/230VAC power cable and protective earth wire.

Wire RS232 serial cable to VME SBC or DCS controller.

Power on,set communication baud rate and station address.

Download HMI screen project,test data reading and keypad operation.

Interface

AC power terminal,RS232 serial port,membrane keypad,display screen,LED indicators:RUN,COM,ALARM.

Feature

NEMA4/4X/12 sealed front panel,dust and splash resistant for industrial field environment.

Integrated display and membrane keypad,all-in-one operator terminal design.

Simple serial communication interface,easy to connect with legacy XYCOM VME control system.

Discontinued obsolete HMI panel,supply only for old production system spare replacement.

Rugged mechanical structure,shock and vibration resistance for continuous long-time operation.

Diagnostic

Check RUN,COM,ALARM LED;no display:check AC power supply and fuse;communication lost:verify serial wiring,baud rate and address setting;keypad no response:inspect membrane keypad circuit and connector.

Product Brief

XYCOM 301993 is legacy panel mount operator HMI panel.

It serves as local operation and monitoring terminal for turbine and compressor control system,widely used for spare replacement in petrochemical and power plant old DCS renovation.

Disclaimer

Product parameters are for reference only and shall not be used as pricing basis. Goods are in short supply and will be powered on for inspection before shipment. Overseas delivery lead time is 3-7 working days. The product is only used for equipment maintenance and transformation.
