XYCOM 90630204 Analog Input Module

Technical Specifications

Model:90630204

Brand:XYCOM

Product type:VME Bus Rack Mount Analog Input Module

Power supply:5V,±12VDC

Bus type:VME bus

Input signal:4-20mA,0-10V analog signal

Resolution:16-bit A/D conversion

Channel:Multi-channel analog input

Mounting:3U VME rack slot

Weight:0.82kg

Operating temperature:0℃ ~ +70℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:5%~95%,non-condensing

Certification:CE,UL

System compatibility

90630204 belongs to XYCOM VME series analog acquisition module.

It can work with XYCOM VME bus SBC such as XYCOM 1840 and XVME series I/O modules.

Compatible with turbine,compressor and legacy DCS control systems.

Commonly used for power plant,oil & gas,petrochemical old equipment monitoring,maintenance and spare replacement.

Function

Multi-channel analog signal collection,convert field current/voltage analog signal to digital data.

16-bit high precision A/D sampling,real-time upload field process value to VME host CPU.

On-board signal filtering,reduce industrial field interference noise.

Over-range and over-voltage fault detection and alarm function.

Support VME bus data read,channel configuration and self-diagnosis.

Installation

Insert the module into 3U VME rack slot and fasten front panel screws.

Connect VME backplane power and bus signal.

Wire field 4-20mA / 0-10V analog sensor cable to terminal block.

Power on,set channel range and VME base address.

Test each channel sampling value and fault alarm function.

Interface

VME backplane connector,analog signal terminal block,LED indicators:RUN,FAULT,ACTIVE.

Feature

Standard 3U VME module,easy to integrate into existing XYCOM VME control rack.

Multi-channel high precision analog acquisition,suitable for temperature,pressure,flow monitoring.

Built-in signal filtering and overvoltage protection,adapt to harsh industrial site.

Discontinued obsolete industrial board,supply only for old production system spare replacement.

Rugged PCB design,shock and vibration resistance for continuous long-time operation.

Diagnostic

Check RUN,FAULT,ACTIVE LED;no communication:check VME backplane power and address setting;sampling abnormal:inspect field sensor wiring and signal range;fault alarm:check over-range input or short circuit.

Product Brief

XYCOM 90630204 is VME bus 3U multi-channel analog input module.

It collects field analog process signals for legacy turbine and compressor control system,widely applied to spare replacement for petrochemical and power plant old DCS renovation.

Disclaimer

Product parameters are for reference only and shall not be used as pricing basis. Goods are in short supply and will be powered on for inspection before shipment. Overseas delivery lead time is 3-7 working days. The product is only used for equipment maintenance and transformation.
