XYCOM 4810SM Operator Interface Terminal

Technical Specifications

Model:4810SM

Brand:XYCOM

Product type:CRT Industrial Operator Interface Terminal

Power supply:115/230VAC auto-switching,50~60Hz,0.16/0.32A

Display:12 inch CRT color display

Input:Relegendable industrial membrane function keypad

Processor:8-bit / 16-bit embedded processor

Memory:Onboard static RAM

Storage:No local hard disk,data stored in host controller

Communication:RS232 serial port,compatible with Hazeltine 1500 terminal emulation

Expansion:Optional auxiliary I/O expansion card

Mounting:Panel mount

Weight:7.7kg

Operating temperature:0℃ ~ +50℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:5%~95%,non-condensing

Front panel:NEMA4/4X

Certification:CE,UL

System compatibility

4810SM belongs to XYCOM 4800 series industrial operator terminal.

It can communicate with XYCOM VME bus SBC such as XYCOM 1840 and XVME series I/O modules.

Compatible with turbine,compressor and legacy DCS control systems via serial communication.

Commonly used for power plant,oil & gas,petrochemical old equipment monitoring,maintenance and spare replacement.

Function

Terminal emulation function,real-time receive and display process data from host controller.

Real-time display process parameter,trend data and system alarm information.

Membrane keypad for setpoint adjustment,mode switching,alarm acknowledge and system operation.

RS232 serial interface for bidirectional data exchange with VME controller,PLC and DCS host.

Built-in self-test circuit for hardware fault detection.

Built-in hardware watchdog timer to ensure stable operation.

Installation

Embed the terminal into cabinet panel cutout and fasten mounting brackets.

Connect 115/230VAC power cable and protective earth wire.

Wire RS232 serial cable to VME SBC or DCS controller.

Power on,set terminal communication parameters and baud rate.

Test communication link,verify display and keypad operation.

Interface

AC power terminal,RS232 serial port,membrane keypad,CRT display,LED indicators:RUN,COM,ALARM.

Feature

NEMA4/4X sealed front panel,dust and splash resistance for harsh industrial field environment.

12-inch industrial CRT display,stable display for long time continuous running.

Dedicated relegendable membrane keypad for process operation.

SM version enhanced signal processing and anti-interference capability.

Terminal-based design,no local disk,low failure rate.

Discontinued obsolete industrial operator terminal,supply only for old production system spare replacement.

Vibration resistant rugged mechanical structure for continuous long-time operation.

Diagnostic

Check RUN,COM,ALARM LED;no display:check AC power supply and CRT circuit;communication lost:verify serial cable,baud rate and address setting;keypad no response:inspect membrane keypad circuit and connector;system abnormal reset:check watchdog and power supply interference.

Product Brief

XYCOM 4810SM is anti-interference enhanced version of 4810 series,legacy 12-inch CRT panel mount industrial operator terminal.

It serves as local HMI and monitoring workstation for turbine and compressor control system,widely used for spare replacement in petrochemical and power plant old DCS renovation.

Disclaimer

Product parameters are for reference only and shall not be used as pricing basis. Goods are in short supply and will be powered on for inspection before shipment. Overseas delivery lead time is 3-7 working days. The product is only used for equipment maintenance and transformation.
