XYCOM 513018503 Communication Interface Module

Technical Specifications

Model:513018503

Brand:XYCOM

Product type:VME Bus Rack Mount Serial Communication Interface Module

Power supply:5V,±12VDC

Bus type:VME bus

Communication port:Multi-channel RS232/RS422 serial interface

Data rate:Up to 115200 baud rate

Mounting:3U VME rack slot

Weight:0.72kg

Operating temperature:0℃ ~ +70℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:5%~95%,non-condensing

Certification:CE,UL

System compatibility

513018503 belongs to XYCOM VME series communication module.

It can work with XYCOM VME bus SBC such as XYCOM 1840 and XVME series I/O modules.

Compatible with turbine,compressor and legacy DCS control systems.

Commonly used for power plant,oil & gas,petrochemical old equipment monitoring,maintenance and spare replacement.

Function

Multi-channel serial data transceiver,realize data exchange between VME host and field HMI or slave controllers.

Support RS232 / RS422 serial protocol,configurable baud rate,data bit,parity and stop bit.

On-board data buffer,reduce bus occupation and improve communication stability.

Channel fault detection,signal break and frame error alarm.

Support VME bus interrupt trigger,data read and write,channel parameter configuration and self-diagnosis.

Installation

Insert the module into 3U VME rack slot and fasten front panel screws.

Connect VME backplane power and bus signal.

Wire serial communication cable to field HMI or peripheral controller.

Power on,set VME base address and serial port communication parameters.

Test each channel data sending and receiving function.

Interface

VME backplane connector,serial signal terminal block,LED indicators:RUN,FAULT,COM STATUS.

Feature

Standard 3U VME module,easy to integrate into existing XYCOM VME control rack.

Multi-channel serial ports,expand communication capacity of VME host CPU.

Built-in signal isolation and surge protection,anti-interference for plant harsh environment.

Discontinued obsolete industrial board,supply only for old production system spare replacement.

Rugged PCB design,shock and vibration resistance for continuous long-time operation.

Diagnostic

Check RUN,FAULT,COM STATUS LED;no communication:check VME backplane power and address setting;data loss:verify serial wiring,baud rate and parity setting;channel error:inspect cable shielding and signal grounding.

Product Brief

XYCOM 513018503 is VME bus 3U multi-channel serial communication module.

It realizes serial data interaction between VME main controller and field HMI equipment for legacy turbine and compressor control system,widely applied to spare replacement for petrochemical and power plant old DCS renovation.

Disclaimer

Product parameters are for reference only and shall not be used as pricing basis. Goods are in short supply and will be powered on for inspection before shipment. Overseas delivery lead time is 3-7 working days. The product is only used for equipment maintenance and transformation.
