XYCOM 8450 Industrial Operator Workstation

Technical Specifications

Model:8450

Brand:XYCOM

Product type:19 Inch Rack Mount Heavy-duty Industrial Operator Workstation

Power supply:115/230VAC,50/60Hz,1.25/2.5A

Display:14 inch CRT color display,support LCD retrofit upgrade kit

Input:Industrial membrane keypad

Communication:RS232 / RS485 serial interface

Weight:27.2kg

Operating temperature:0℃ ~ +55℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:5%~95%,non-condensing

Certification:CE,UL,Class I Division2

System compatibility

8450 belongs to XYCOM 8400 series rack mount operator workstation.

It can communicate with XYCOM VME bus SBC such as XYCOM 1840 and XVME series I/O modules.

Compatible with turbine,compressor and legacy DCS control systems via serial port.

Commonly used for power plant,oil & gas,petrochemical old equipment monitoring,maintenance and spare replacement.

Function

Real-time display process parameters,trend curves,system alarms and equipment running status.

Membrane keypad for parameter setting,operation mode switching and manual control command input.

Bidirectional serial data exchange with VME main controller.

Local visual alarm indication when process abnormal occurs.

Power-on self-test for onboard hardware circuit detection.

Support XYCOM SoftScreen HMI configuration software for screen project upload and download.

Store alarm records and simple operation event logs.

Installation

Mount the unit into 19-inch cabinet rack and tighten fixing screws.

Connect 115/230VAC power cable and protective earth wire.

Wire serial communication cable to VME controller serial port.

Power on and run hardware self-test,configure serial baud rate and station address.

Download HMI project,verify keypad,CRT display and serial communication function.

Interface

AC power terminal,RS232/RS485 serial port,14 inch CRT display,membrane keypad,LED indicators:PWR,COMM,ALARM.

Feature

Standard 19-inch rack heavy-duty workstation design,built-in industrial computer host.

14-inch CRT color display,support later LCD retrofit upgrade kit for old CRT replacement.

Heavy-duty sealed membrane keypad,dust and oil resistant for workshop environment.

Dedicated serial interface to connect XYCOM VME control platform.

Rugged metal chassis,shock and vibration resistant for continuous long-time operation.

Discontinued legacy product,only used for old production system maintenance spare replacement.

Diagnostic

Check PWR and COMM LED;communication failure:check serial wiring,baud rate and station address;data abnormal:inspect keypad,CRT display tube and serial port hardware.

Product Brief

XYCOM 8450 is 8400 series heavy-duty rack mount industrial operator workstation.

It cooperates with XYCOM VME bus control system for field process monitoring and manual operation,widely used as spare parts for turbine and petrochemical old DCS control system renovation.
