Yokogawa ADMAG AXF Magnetic Flowmeter

Feature & Principle

It is Yokogawa ADMAG AXF series electromagnetic flowmeter, based on Faraday electromagnetic induction law. Adopts dual-frequency excitation technology, strong anti-fluid noise ability. It has electrode adhesion diagnosis, empty pipe detection and self-diagnosis functions. It supports integral or remote separated installation, infrared operation without opening cover. Optional HART, FOUNDATION Fieldbus communication. This model is discontinued and widely used as maintenance spare for water, slurry and corrosive liquid flow measurement.

Specifications

Model: ADMAG AXF Brand: Yokogawa Accuracy: ±0.35% of reading (high precision ±0.2%) Excitation: Dual frequency / enhanced dual frequency Output: 4-20mA, HART, FF fieldbus Size range: DN2.5 ~ DN400 Lining: Rubber, PFA, hard rubber Power supply: 24VDC Installation: Integral / remote separated type Certification: ATEX, IECEx, CE Application: Water treatment, chemical, pulp, mining slurry conductive liquid metering

Components & Diagnostics

Flow tube, measuring electrode, excitation coil, converter mainboard, LCD display, sealing lining. Common faults: electrode fouling, empty pipe alarm, signal jump, lining damage, communication failure.

Product Brief

AXF electromagnetic flowmeter, Yokogawa ADMAG series conductiv
