Yokogawa RCCS38‑A04A2SL DCS I/O Module Unit

Module Feature

RCCS38‑A04A2SL is Yokogawa CENTUM CS3000 DCS remote I/O module. It is installed in remote I/O rack, responsible for collecting on‑site analog and digital signals and executing output control commands from the control station. It communicates with FCS control station through the remote bus, supports hot swap function, widely used in chemical, petrochemical and thermal power process control systems.

Working principle

The module receives commands and parameter data from FCS via remote I/O bus. It samples field sensor signals and converts them into digital bus data and uploads to controller. It converts control instructions into field output signals to drive on‑site actuators.

Onboard components

Signal acquisition circuit, bus communication chip, signal isolation unit, terminal connector, status LED, PCB and modular housing.

LED indicators

LEDs show power, bus link, running and fault alarm status.

Hardware self‑diagnosis

Detect bus communication failure, channel overrange, short circuit and power supply abnormality, view diagnostic information via CS3000 engineering station.

Programming software

Configuration and commissioning by Yokogawa CS3000 engineering software.

Electrical & Process Parameters

Model:RCCS38‑A04A2SL Brand:Yokogawa Device type:Remote I/O Module Applicable system:CENTUM CS3000 DCS Function:Field signal collection and control output for DCS system

Mechanical & Structure

Mounting:Remote I/O rack slot mounting Protection class:IP20 Housing:Modular plastic housing

Environmental

Operating temperature:0℃ ~ +55℃ Storage temperature:-20℃ ~ +85℃ Ambient humidity:5~90% non‑condensing Certification:CE process automation standard compliant Status: Yokogawa original CS3000 series I/O module

Installation

Insert module into remote I/O rack slot and lock. Wire field sensors and actuators to terminal block, complete hardware configuration in engineering software and download to FCS.

Interface

DCS remote bus interface, field signal wiring terminals.

Diagnostic

Bus communication interruption: bus cable fault or terminal resistor missing. Channel abnormal: sensor wiring error or channel burnout. Module alarm: read diagnostic message from CS3000 system.

Product Brief

Yokogawa RCCS38‑A04A2SL remote I/O module, signal acquisition and output card for CENTUM CS3000 DCS control system.
