Yokogawa SR1030B62 Servo Actuator Spare Part

Technical Specifications

Model:SR1030B62

Brand:Yokogawa

Part No:SR1030B62

Product type:Direct drive brushless servo actuator

Rated voltage:230V AC

Rated capacity:1500VA

Continuous torque:30Nm

Max speed:500rpm

Protection class:IP65

Dimension:260mm210mm120mm

Weight:18.2kg

Feedback interface:High resolution built-in encoder

Mounting:Flange direct mounting

Operating temperature:0~40℃

Storage temperature:-20~70℃

Relative humidity:5~95% non-condensing

Certification:CE

System compatibility

SR1030B62 belongs to Yokogawa Dynaserv DD servo family,matched with Yokogawa Dynaserv dedicated servo drives,widely used in precision machine tools,rotary indexing tables,packaging machinery,printing and textile high-precision rotary axes.This is discontinued industrial spare part for equipment overhaul and maintenance.

Function

SR1030B62 is integrated outer rotor direct drive servo actuator.It eliminates gearbox,realizes direct rotary output,features high rigidity,zero backlash and ultra-precise positioning.Built-in high resolution encoder feeds back angle and speed signal for closed-loop motion control.Low cogging torque,smooth rotation,good dynamic response,suitable for heavy-duty high precision indexing and continuous rotary working scenarios.

Installation

Install SR1030B62 via flange direct mounting on machine base.Connect 230V AC power cable and encoder feedback cable.Fasten mounting bolts,complete shielding and grounding inspection before power-on test.

Interface

‑230V AC power terminal

‑Built-in high resolution encoder feedback connector

‑Shield grounding terminal

Feature

SR1030B62 is obsolete Yokogawa spare part.Typical faults:encoder damage,winding insulation aging,bearing wear,connector pin corrosion.Test winding resistance,insulation resistance and encoder position signal before replacement.

Diagnostic

Actuator faults will trigger overload,overcurrent or position tracking alarm;actuator fails to rotate,position jitter,rotary positioning deviation,intermittent motion stop.

Built‑in function:Convert electrical command into direct rotary mechanical torque,realize high accuracy rotary positioning without gear reducer,as Yokogawa Dynaserv series DD servo actuator spare replacement.

Product Brief

SR1030B62 is Yokogawa Dynaserv direct drive servo actuator,230V AC,30Nm continuous torque,built-in high resolution encoder,gearless rotary output,used for heavy-duty high-precision rotary automation equipment maintenance.Confirm encoder specification and drive compatibility before ordering.ESD protection required during handling and installation.
