Rexroth 093C-0-DC-4-C/110-A2/WI573LV/S005 Spare Part

Technical Specifications

Model:093C-0-DC-4-C/110-A2/WI573LV/S005

Brand:Custom Industrial Fluid Control

Product type:Direct acting solenoid valve

Power supply:110V DC

Control function:Fluid on-off switching,flow cut-off,coil self-protection,hardware self-diagnosis,fault indication

Communication:No digital bus

Mounting:Pipeline threaded mounting

Operating temperature:0~60℃

Storage temperature:-20~70℃

Relative humidity:5~95% non-condensing

Max working altitude:2000m

Weight:0.95kg

Dimension:135mm72mm68mm

Certification:CE

Protection class:IP65

System compatibility

093C-0-DC-4-C/110-A2/WI573LV/S005 belongs to industrial fluid control valve series,matched with PLC,pressure sensor and pipeline components.Widely applied in automation production line,hydraulic and pneumatic fluid control workstations.This is a discontinued legacy spare part for equipment maintenance replacement.

Function

093C-0-DC-4-C/110-A2/WI573LV/S005 is a direct acting solenoid valve for industrial fluid control.It uses electromagnetic coil to drive valve core movement to realize pipeline fluid opening and closing.It can cut off or connect medium flow according to electrical control signal.It integrates coil overheat protection to avoid burnout under long-time energization.It feeds back valve working status for system monitoring.It acts as fluid on-off execution component for industrial automation workstation.

Installation

Install 093C-0-DC-4-C/110-A2/WI573LV/S005 on pipeline thread port and tighten the valve body.Ensure fluid flow direction matches the marking on valve body.Connect 110V DC power wiring according to wiring drawing.Check sealing performance before system power-on.

Interface

‑110V DC coil power terminal

‑Threaded medium inlet port

‑Threaded medium outlet port

‑Valve status indicator

Circuit feature

Built-in coil surge suppression circuit,protect control signal from electromagnetic interference,suitable for industrial workshop environment.

Feature

093C-0-DC-4-C/110-A2/WI573LV/S005 is obsolete industrial spare part.Typical faults:valve fails to open/close,coil burnout,medium leakage,thread corrosion.Inspect coil,valve core and sealing gasket before replacement.This valve must match corresponding fluid medium and pipeline pressure,direct substitution without inspection is not recommended.

Diagnostic

When coil damage,valve core stuck or sealing failure occurs,the system will report fluid control abnormal alarm.

Built‑in function:Pipeline fluid on-off control,coil overheat protection,status monitoring,self-diagnosis and fault alarm,used as industrial fluid control system spare replacement.

Product Brief

093C-0-DC-4-C/110-A2/WI573LV/S005 is old direct acting solenoid valve for industrial fluid control workstation.Confirm medium type,working pressure and power supply before ordering.ESD protection required during handling and installation.
