100198923AB Signal Interface Board Unit

Module Feature

100198923AB is a pluggable printed circuit board assembly designed for industrial distributed control cabinets.

It integrates signal filtering, isolation and conversion circuits to receive 4–20mA analog signals and dry contact digital signals from field transmitters, limit switches and solenoid valves. The isolation circuit suppresses electromagnetic interference generated by inverters and heavy-load motors on site. It adopts gold finger hot-swap structure, widely used for spare replacement and cabinet retrofitting in chemical, power and metallurgical plants.

Working principle

Field discrete and analog signals pass through onboard filtering and isolation circuits.

The conditioned signals are converted into digital data and transmitted to the main controller via backplane bus. The board monitors channel status continuously and reports fault flags to upper engineering software when open circuit, short circuit or abnormal signal is detected.

Onboard components

Signal conditioning chips, isolation modules, backplane gold finger connector, SMD electronic components, onboard LED indicator array.

LED indicators

Onboard LEDs show power supply status, running state and fault alarm.

Hardware self‑diagnosis

The matched DCS controller continuously monitors power supply abnormality, gold finger contact fault and signal channel failure, and fault codes can be viewed through upper engineering software.

Programming software

Vendor dedicated configuration tool, used for signal channel calibration, alarm threshold setting and fault log query.

Electrical & Process Parameters

Model:100198923AB Brand:Unspecified Device type:DCS signal I/O board Supply voltage:24V DC Function:Field instrument analog and digital signal collection and backplane communication for industrial process control

Mechanical & Structure

Mounting:Plug-in installation on system chassis backplane

Protection class:IP20

Housing:PCB assembly with metal shielding frame

Environmental

Operating temperature:0℃ ~ +60℃

Storage temperature:-40℃ ~ +85℃

Ambient humidity:5~95% non‑condensing

Certification:CE

Status:Original industrial automation spare

Installation

Cut off cabinet power supply before replacement, insert the board into the designated slot and lock the fasteners.

Wire field instrument cables according to schematic drawing, verify bus communication and signal sampling function after power on.

Interface

Backplane bus gold finger connector, field signal wiring terminal block.

Diagnostic

Board offline: Damaged gold finger or loose locking buckle.

Signal reading abnormal: Failed isolation circuit or reversed wiring polarity.

No LED light: Missing 24V DC power supply.

Product Brief

100198923AB industrial PCB assembly, DCS signal input output interface card for power and chemical plant cabinet maintenance replacement.
