100405991 Pressure Sensor Assembly Unit

Module Feature

100405991 is a replacement sensing core assembly for industrial pressure transmitter.

It adopts stainless steel diaphragm and piezoresistive sensing chip design, with built-in temperature compensation circuit. The assembly is sealed and calibrated at factory, supports gauge or absolute pressure measurement. It can be integrated into smart pressure transmitter housing, compatible with 4-20mA+HART electronic board. Anti-corrosion wetted material makes it suitable for water, oil and light corrosive medium. This part is commonly stocked as maintenance spare for on-site transmitter repair.

Working principle

Process pressure acts on the metal diaphragm, transfers stress to the piezoresistive sensing chip.

The chip converts mechanical strain into millivolt electrical signal. The internal compensation circuit offsets temperature drift. The signal is then sent to transmitter electronic board for amplification and conversion to standard 4-20mA output.

Onboard components

Piezoresistive sensing chip, stainless steel isolation diaphragm, oil-filled transfer medium, temperature compensation resistor, hermetically sealed metal housing, process pressure port.

LED indicators

Not applicable, passive sensing assembly without indicator. Status is displayed by matched transmitter electronic unit.

Hardware self‑diagnosis

No independent self-diagnosis. Fault detection is realized by transmitter electronics to check signal out-of-range, open circuit and short circuit.

Programming software

Not applicable, calibrated at factory.

Electrical & Process Parameters

Model:100405991 Brand:OEM transmitter sensing component Device type:Sealed pressure sensor core assembly Function:Pressure to electrical signal conversion for process pressure transmitter

Mechanical & Structure

Mounting:Threaded installation inside transmitter housing Protection class:IP67 after full assembly Housing:316L stainless steel sealed capsule

Environmental

Operating temperature:-40℃ ~ +125℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:5~95% non‑condensing

Certification:CE

Status:Original OEM transmitter spare

Installation

Isolate process pressure and depressurize before disassembly.

Align thread and torque to specification, avoid diaphragm damage during installation, perform zero calibration after assembly.

Interface

Process pressure thread port, signal pin interface for transmitter electronic board.

Diagnostic

No pressure signal: Diaphragm rupture, internal oil leakage or sensing chip failure. Large zero drift: Sensor overload, medium crystallization or temperature compensation failure. Signal noisy: Diaphragm vibration or internal seal damage.

Product Brief

100405991 pressure sensor assembly, sealed sensing core spare for industrial smart pressure transmitter repair replacement.
