1014373 Eddy Current Signal Conditioner

Feature & Principle

It outputs high-frequency excitation signal to drive the eddy current probe. It demodulates and processes the impedance change signal caused by metal target gap, outputs proportional analog signal to monitoring system or PLC. It can detect probe open circuit, short circuit fault and trigger alarm, with gain and zero point adjustable.

Specifications

Model: 1014373 Power supply: 24VDC Output: Linear analog voltage signal Compatible: Series eddy current probe and extension cable Mounting: Rack / DIN rail installation Protection grade: IP40 Application: Steam turbine, gas turbine, centrifugal compressor Certification: CE

Components & Diagnostics

High frequency oscillation circuit, signal demodulation unit, adjustment potentiometer, status LED indicator, probe terminal block. Common faults: no excitation output, signal non-linear, zero drift, false cable fault alarm, power circuit burnout.

Product Brief

1014373 signal conditioner, rotating equipment monitoring spare widely used for power plant turbine and large compressor vibration monitoring cabinet maintenance and replacement.
