10197723 Eddy Current Signal Conditioner

Feature & Principle

It generates high-frequency excitation signal to drive eddy current probe. The internal circuit demodulates and linearizes impedance variation caused by metal clearance, and outputs analog signal to TSI monitoring rack or PLC. It has built-in cable fault detection function, triggers alarm when probe open or short circuit, zero point and gain can be adjusted on site.

Specifications

Model: 10197723 Power supply: 24VDC Output: Linear analog voltage signal Compatible series: 450 eddy current probe and extension cable Mounting: Rack plug-in installation Protection grade: IP40 Application: Steam turbine, gas turbine, centrifugal compressor Certification: CE

Components & Diagnostics

High frequency oscillation circuit, signal demodulation circuit, adjustable potentiometer, status LED indicator, probe wiring terminal. Common faults: no excitation output, signal non-linear distortion, zero drift, false cable fault alarm, power circuit burnout.

Product Brief

10197723 signal conditioner, rotating equipment monitoring spare widely used for power plant turbine and large compressor vibration monitoring cabinet maintenance and replacement.
