EL-1132 Proximity Sensor

Feature & Principle

It adopts inductive eddy current sensing principle. The internal oscillation circuit generates high-frequency electromagnetic field. When metal object approaches the sensing surface, eddy current suppresses oscillation and triggers output state change. It has non-contact detection characteristic, no mechanical wear, good vibration resistance and anti-interference performance.

Specifications

Model: EL-1132 Type: Inductive proximity switch Detection object: Metal Output type: NPN / PNP switching output Supply voltage: 10~30VDC Detection distance: Standard sensing range Connection: Cable or plug connection Protection grade: IP67 Certification: CE

Components & Diagnostics

Sensing coil, oscillation circuit, signal processing unit, status LED indicator, cable terminal. Common faults: no detection response, false triggering, signal loss, short circuit burnout, wiring damage.

Product Brief

EL-1132 proximity sensor, automation spare widely used for machine tools, conveyor lines and packaging equipment position monitoring and replacement.
