1400-384C Pressure Switch

Feature & Principle

It is a mechanical pressure control switch. Process pressure acts on the internal sensing diaphragm or piston assembly. When the pressure reaches the preset threshold, it triggers the snap-action micro switch to realize dry contact on-off signal output. The action set value can be adjusted on site by screw. No external power supply is required for sensing part, stable action and small dead band, used for pressure high/low alarm and equipment interlock protection.

Specifications

Model: 1400-384C Sensing element: Diaphragm / Piston type Contact type: SPDT snap action Contact rating: 250VAC Wetted material: 316 stainless steel Protection class: IP65 Process connection: Standard thread Mounting: Surface mounting Application: Water treatment, energy equipment, chemical pipeline pressure interlock and alarm Certification: CE

Components & Diagnostics

Sensing assembly, micro switch, adjustment screw, metal housing, wiring terminal, sealing ring. Common faults: diaphragm damage and leakage, contact ablation, set point drift, switch no action.

Product Brief

1400-384C pressure switch, industrial pressure control spare widely used for pipeline and pump protection overhaul and replacement.
