1426-M6E Pressure Transmitter Unit

Feature & Principle

It adopts piezoresistive sensing principle. The pressure acts on the sensing diaphragm, the internal Wheatstone bridge converts the strain change into electrical signal, and outputs standard 4-20mA signal after temperature compensation and signal conditioning for PLC and DCS acquisition.

Specifications

Model: 1426-M6E Output: 4-20mA Power supply: 10~30VDC Wetted material: Stainless steel Process connection: Threaded Protection: IP67 Certification: CE

Components & Diagnostics

Sensing diaphragm, signal conditioning circuit, metal housing, cable entry gland, electrical terminal. Common faults: zero point drift, no signal output, diaphragm damage, poor contact of wiring.

Product Brief

1426-M6E pressure transmitter, process spare widely used for water treatment, machinery, chemical and energy industry pressure detection.
