P14391NM7M0510J Pressure Transmitter Unit

Feature & Principle

It uses piezoresistive sensing element. Process pressure deforms the internal diaphragm, Wheatstone bridge converts strain signal into standard 4-20mA analog signal. Built-in temperature compensation circuit reduces measurement drift, transmits stable pressure value to PLC and DCS for control and interlock.

Specifications

Model: P14391NM7M0510J Output: 4-20mA Power supply: 10~30VDC Wetted material: Stainless steel Process connection: Threaded Protection: IP67 Certification: CE

Components & Diagnostics

Sensing diaphragm, signal conditioning PCB, stainless steel housing, cable gland, electrical connector. Common faults: zero drift, signal loss, diaphragm corrosion, wiring loose.

Product Brief

P14391NM7M0510J pressure transmitter, process spare widely used for petrochemical, water treatment and hydraulic system pressure monitoring.
