3070123 Eddy Current Signal Conditioner

Feature & Principle

It supplies high-frequency excitation signal to the probe coil, detects impedance change caused by eddy current effect. After internal signal demodulation and linear processing, it outputs proportional analog signal to PLC or monitoring instrument. It supports gain adjustment and zero setting, and provides fault alarm when probe cable is open or short.

Specifications

Model: 3070123 Power supply: 24VDC Output signal: Linear voltage signal Compatible sensor: 460 series eddy current probe Mounting: DIN rail or rack mount Protection grade: IP40 Certification: CE

Components & Diagnostics

High-frequency oscillation circuit, signal demodulation unit, adjustment potentiometer, status LED, probe terminal block. Common faults: no excitation output, signal non-linear, open circuit false alarm, zero point drift, power supply damage.

Product Brief

3070123 signal conditioner, rotating equipment monitoring spare widely used for turbine, compressor and large pump vibration protection cabinet maintenance and replacement.
