35071573 Termination Board Unit

Feature & Principle

It receives analog and digital signals from speed probes, pressure transmitters and limit switches on site. It provides terminal wiring interface, signal filtering and surge suppression, and transmits stable conditioned signals to the main control board for logic operation and protection judgment.

Specifications

Model: 35071573 Type: Signal termination board Power supply: 5V / 24VDC Mounting: Rack plug-in Application: Turbine control cabinet Certification: CE

Components & Diagnostics

Signal filter circuit, surge protection components, terminal block, backplane connector, status indicator LED. Common faults: loose terminals, signal attenuation, surge damage, backplane communication abnormality.

Product Brief

35071573 termination board, industrial control spare widely used for power plant turbine control and DCS system maintenance.
