35071619-1 Termination Board Unit

Feature & Principle

It receives analog and digital field signals from speed probes, transmitters and limit switches. It provides terminal wiring interface, signal filtering and surge suppression, transmits conditioned stable signals to main control board for logic operation and protection judgment.

Specifications

Model: 35071619-1 Type: Signal termination board Power supply: 5V / 24VDC Mounting: Rack plug-in Application: Turbine control cabinet Certification: CE

Components & Diagnostics

Signal filter circuit, surge protection components, terminal block, backplane connector, status indicator LED. Common faults: loose terminals, signal attenuation, surge damage, backplane communication abnormality.

Product Brief

35071619-1 termination board, industrial control spare widely used for power plant turbine control and DCS system maintenance.
