5P5B1H-L0U8 Pressure Transmitter

Feature & Principle

It is a compact intelligent pressure transmitter. It adopts piezoresistive sensing principle, the pressure acts on the sensing diaphragm and converts tiny strain change into electrical signal. After internal temperature compensation and signal conditioning, it outputs standard 4-20mA analog signal superimposed with HART digital signal. It supports remote zero and span calibration through HART communicator, good anti-interference performance, compact structure, easy installation on pipeline or tank, used for real-time pressure monitoring and closed-loop control.

Specifications

Model: 5P5B1H-L0U8 Signal: 4-20mA + HART Power supply: 10.8 ~ 42 VDC Sensing type: Piezoresistive Wetted material: 316L stainless steel Protection class: IP65 Process connection: Standard thread Mounting: Direct pipe mounting or bracket mounting Application: Chemical pipeline, water treatment, energy equipment pressure and level monitoring Certification: CE

Components & Diagnostics

Piezoresistive sensor core, electronic circuit board, LCD display option, stainless steel process body, sealing gasket. Common faults: zero drift, no current output, HART communication failure, diaphragm damage and medium leakage.

Product Brief

5P5B1H-L0U8 pressure transmitter, industrial process pressure instrument spare widely used for pipeline and tank pressure measurement overhaul and replacement.
