5P5B2F-5U35 Solenoid Valve Unit

Feature & Principle

It adopts electromagnetic pilot control principle. After the coil is energized, the pilot spool acts to change the pressure balance inside the valve body, driving the main valve to open or close, so as to connect or cut off the medium pipeline. It receives switch signals from PLC and DCS to realize remote automatic fluid on-off control.

Specifications

Model: 5P5B2F-5U35 Type: Pilot solenoid valve Controlled medium: Compressed air, water, light oil Voltage: 24VDC / 110VAC Connection: Thread connection Protection: IP65 Certification: CE

Components & Diagnostics

Electromagnetic coil, pilot spool assembly, main valve diaphragm/piston, valve body, sealing gasket, wiring terminal. Common faults: coil burnout, diaphragm aging leakage, valve stuck, slow action, sealing surface fouling.

Product Brief

5P5B2F-5U35 solenoid valve, fluid control spare widely used for chemical, water treatment, packaging equipment and pneumatic system pipeline control.
