FMR50-87N0 Radar Level Transmitter Unit

Feature & Principle

It adopts time-of-flight radar measurement principle. The antenna emits microwave pulses, the pulses reflect back from the material surface, and the electronic unit calculates distance and converts it into level value. It is not affected by vapor, temperature and pressure changes, supports HART communication, Heartbeat diagnostic function and multi-echo tracking for stable measurement.

Specifications

Model: FMR50-87N0 Brand: Endress+Hauser Series: Micropilot FMR50 Output: 4-20mA HART Accuracy: ±2mm Ambient temperature: -40 ~ +80℃ Process connection: Thread / Flange Certification: CE, SIL2 Protection: IP66

Components & Diagnostics

Radar antenna, RF transmitting and receiving circuit, main electronic module, LCD display, terminal compartment. Common faults: antenna fouling, echo loss, signal drift, HART communication failure, water ingress in housing.

Product Brief

FMR50-87N0 radar level transmitter, E+H instrument spare widely used for chemical, water treatment, oil and gas tank continuous level monitoring.
