A05B-2500-C003 Backplane Rack Unit

Feature & Principle

It serves as the hardware base bus rack of the R-30iA robot cabinet. It provides internal bus signal and power interconnection for each plug-in module, and the built-in dual fans realize forced air cooling for all control boards. It transmits control signals and power between modules to ensure the stable operation of robot motion control, logic and safety circuits.

Specifications

Model: A05B-2500-C003 Brand: FANUC Applicable system: R-30iA robot controller Slot quantity: 4 slots Cooling: Built-in dual fans Mounting: Install inside robot control cabinet Certification: CE

Components & Diagnostics

Backplane bus circuit board, dual fan assembly, power terminal block, module guide slot, signal connector. Common faults: fan stall alarm, bus communication failure, poor contact of slot pins, overheating, power supply short circuit.

Product Brief

A05B-2500-C003 backplane rack, FANUC robot spare widely used for handling, welding and palletizing R-30iA robot cabinet overhaul and replacement.
