ABB 3AXD50000000753 AFPS‑61C Power Supply Board

Technical Specifications

Model:3AXD50000000753(AFPS‑61C)

Brand:ABB

Product Type:Inverter internal control power supply board

Applicable Drive:ABB ACS600 series frequency converter

Input:Obtain power from main circuit intermediate DC bus

Output:Multi‑channel isolated control auxiliary power

Protection:Over‑voltage,over‑current,short‑circuit,over‑temperature protection

Feature:On‑board fault detection,compact plug‑in PCB structure

System Compatibility:ABB ACS600 series variable frequency drive

Remark:Legacy EOL spare component;replace strictly according to part number

Module Form:Plug‑in printed circuit board

Weight:0.50 kg

Dimension:178 mm×127 mm×76 mm

Protection Grade:IP20

Certification:CE

Working Temperature:‑10℃ ~ +60℃,non‑condensing

Storage Temperature:‑40℃ ~ +85℃

Humidity:5%‑95% non‑condensing

Application:Petrochemical,power plant,metallurgy industrial site,used for ACS600 series inverter internal control power supply,equipment overhaul and spare‑part replacement.

Product Details

3AXD50000000753,part number AFPS‑61C,is internal control power supply board for ABB ACS600 series variable frequency drive. It takes energy from DC bus of drive main circuit and converts to multiple groups of isolated auxiliary power for main control board,trigger unit and signal loop of frequency converter.

Built‑in complete protection mechanism against over‑voltage,over‑current,short‑circuit and over‑temperature. Adopts plug‑in PCB structure for convenient disassembly and maintenance. It is a key vulnerable component of ACS600 drive;power supply board failure will cause inverter no display,unable to start or fault alarm. Widely used for on‑site maintenance and overhaul of ABB ACS600 series drives.

Note:This is legacy EOL spare component,widely used for industrial drive spare‑part replacement.
