ABB 57520001‑EV DSCS140 MasterBus300 Communication Processor

Technical Specifications

Model:57520001‑EV(DSCS140)

Brand:ABB

Product Type:MasterBus300 communication processor module

Bus Protocol:ABB proprietary MasterBus300

Data Rate:2Mbps

Power Supply:Rack backplane power supply

Communication Interface:MasterBus300 bus interface,rack backplane bus connector

Redundancy:Support communication redundancy function

Indicator:Power,running,communication,fault LED indicators

Feature:Rack plug‑in installation,on‑board self‑diagnosis function

System Compatibility:ABB Advant Master,Advant OCS,S100 I/O DCS system

Remark:Legacy EOL spare component;confirm rack slot and redundancy configuration before replacement

Module Form:Rack‑mount plug‑in PCB board

Weight:0.36 kg

Dimension:234 mm×100 mm×25 mm

Protection Grade:IP20

Certification:CE

Working Temperature:‑10℃ ~ +60℃,non‑condensing

Storage Temperature:‑40℃ ~ +85℃

Humidity:5%‑95% non‑condensing

Application:Power plant,petrochemical,papermaking industry,acts as core communication processor between Advant controller and S100 I/O racks,completes high‑speed real‑time data transmission of whole‑rack I/O signals,supports redundant link transmission,system overhaul and spare‑part replacement.

Product Details

57520001‑EV,type DSCS140,is MasterBus300 communication processor for ABB Advant series DCS system.

It undertakes data gateway function between upper‑level controller and S100 I/O racks,adopts proprietary MasterBus300 protocol with 2Mbps rate,realizes real‑time interaction of analog/digital signals between controller and I/O modules;supports communication redundancy to improve system reliability. Rack plug‑in structure,equipped with multi‑group LED for running status and fault diagnosis. Module failure will cause corresponding S100 I/O rack offline,loss of all I/O signals of the whole rack. Widely used for legacy Advant DCS site maintenance.

Note:This is legacy EOL spare component,widely used for process industry spare‑part replacement.
