Advantech TPC1570HC1A0001E Panel PC Unit

Module Feature

TPC1570HC1A0001E belongs to Advantech TPC-1570H legacy industrial panel PC series.

It adopts 15-inch XGA 1024×768 TFT LCD with resistive touchscreen, built-in Intel Celeron M 1GHz CPU, fanless heat dissipation design to avoid dust and fan failure risk. It supports 18~32VDC wide range DC power supply, integrates 10/100M Ethernet, RS232/485 serial communication, USB and VGA interface. The aluminum-magnesium alloy front panel supports panel flush mounting, supports Windows XP / WinXPe operating system, with watchdog timer function, widely deployed as HMI host for packaging machinery, production line, water treatment and factory automation control.

Working principle

The embedded industrial mainboard runs HMI configuration software, collects data from PLC and field instruments through serial port or Ethernet.

Touch screen receives operator’s touch command, uploads operation instruction to control system, and displays real-time process parameters, alarm information and trend curve on LCD screen. Watchdog circuit automatically resets the system when program crash occurs to improve field operation stability.

Onboard components

TFT LCD display, resistive touch panel, embedded main control motherboard, aluminum alloy heat sink, DC power supply module, communication interface chip, status indicator board, mounting clamping bracket set.

LED indicators

Front LEDs indicate power on status, hard disk activity and network communication running status.

Hardware self‑diagnosis

Built-in watchdog and power monitoring circuit. System self-test information can be viewed during BIOS startup; operating system and HMI software record communication offline, touch failure and disk fault logs.

Programming software

Advantech driver package + third-party HMI configuration software, used for screen picture editing, PLC communication parameter setting, alarm and data recording.

Electrical & Process Parameters

Model:TPC1570HC1A0001E Brand:Advantech Device type:Fanless industrial touch panel PC Function:On-site man-machine interaction, data display and operation control for industrial automation equipment

Mechanical & Structure

Mounting:Panel flush mounting with clamps Protection class:IP65 front panel Housing:Aluminum-magnesium alloy front frame, ABS+PC rear housing

Environmental

Operating temperature:0℃ ~ +50℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:5~95% non‑condensing

Certification:CE, FCC, UL, CCC

Status:Discontinued legacy Advantech industrial panel spare

Installation

Open the cabinet panel opening matching the dimension, fix the panel with mounting clamps from rear side.

Connect 24VDC power cable, Ethernet and serial communication wiring, install operating system and HMI project before commissioning.

Interface

RJ45 Ethernet port, RS232/RS485 serial port, USB port, VGA output, DC power terminal block, audio port.

Diagnostic

No display: DC power supply abnormal, backlight aging or mainboard failure. Touch no response: Touch controller driver exception, touch film damage or wiring loose. Communication intermittent: Serial port parameter mismatch, network cable poor contact or EMC interference.

Product Brief

Advantech TPC1570HC1A0001E panel pc, 15-inch fanless resistive touch industrial HMI spare for production line and machine automation control cabinet replacement.
