Allen Bradley 80173-109-01 GU-D08 SGCT Drive Board

Feature & Principle

It is Allen Bradley GU-D08 integrated SGCT gate drive board, built-in SGCT gate commutated thyristor chip. It receives control pulse from main control board, outputs drive signal to control SGCT turn-on and turn-off. It integrates sampling, pulse shaping, fault feedback and high voltage isolation circuit, strong anti-interference capability, used inside medium voltage inverter power cell. This model is obsolete, only for maintenance spare replacement.

Specifications

Model: 80173-109-01 (GU-D08) Brand: Allen Bradley Device type: SGCT gate commutated thyristor integrated drive board Application: Medium voltage high power inverter power unit Protection: Overcurrent, overvoltage, drive fault detection Installation: Power unit plug-in Certification: CE

Components & Diagnostics

SGCT power chip, pulse transformer, sampling circuit, electrolytic capacitor, status LED, high voltage terminal. Common faults: drive pulse missing, capacitor aging, channel no output, drive fault alarm.

Product Brief

80173-109-01 SGCT drive board, Allen Bradley medium voltage inverter power spare widely used for high-power speed control cabinet overhaul and replacement.
