ALSTOM AM164 Analog Output Module

Technical Specifications

Model：AM164

Brand：ALSTOM

Product Type：Analog output module

Applicable System：ALSTOM Alspa 3300‑50 control rack,turbine governor system

Supply Voltage：24V DC backplane power supply

Output Channel：4‑channel analog output

Signal Range：4‑20mA,0‑10V configurable

Resolution：16‑bit

Isolation Voltage：1500V AC channel‑to‑backplane galvanic isolation

Communication Interface：Rack backplane internal system bus

Status Indicator：Multi‑color LED for power,channel status and module fault

Built‑in Function：Digital‑to‑analog conversion,output signal conditioning,diagnostic monitoring for actuator control loop

Working Temperature：‑10℃ ~ +60℃

Storage Temperature：‑20℃ ~ +70℃

Protection Class：IP20

Mounting：Plug‑in slot installation inside control rack

Weight：0.46kg

Product Brief:

AM164 is legacy plug‑in analog output module for ALSTOM Alspa 3300‑50 control rack,mainly used in steam turbine governor system. It converts digital control commands from main controller into standard analog 4‑20mA or 0‑10V signals to drive hydraulic actuators,valve positioners and field regulating equipment. Each channel features galvanic isolation to suppress field interference and improve control stability. It receives configuration data and power supply through rack backplane bus. Front‑panel LED indicators support quick on‑site channel fault diagnosis without extra testing tools. Plug‑in cabinet mounting structure enables convenient disassembly and module replacement. This is EOL discontinued spare part,widely used for thermal power plant turbine governor system maintenance and renovation. Please confirm hardware revision,signal range configuration and rack compatibility before purchase. Strict ESD anti‑static protection shall be performed during installation.
